MIL-DTL-3950/14A
TABLE IV. Frame, rocker, rocker color selection table.
Frame
Rocker
Rocker color
Style
Code
Style
Code
Color
Code
letter
number
letter
W
Flush
White opaque
R
panel
F
Smooth
1
Red opaque
B
Black opaque
T
Translucent white
C
Colorless (transparent) 1/
Sub
panel
S
Serrated
2
1/ A printed legend insert or decal can be located inside of rocker button. Recommend size of
insert is .750 +.000, -.010 by 1.100 +.000, -.010. Legend insert is not furnished as part of switch.
Military Part or Identifying Number (PIN): The PIN shall consist of the prefix M3950/14, followed in order
by the appropriate alpha letter designating poles, two digit circuit code number, and the code letter or
number for the frame style, rocker style, and rocker color as shown in the following example:
3950/14
X
XX
X
X
X
M
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Military designation
l
l
l
l
l
l
l
l
l
l
l
Specification sheet number
l
l
l
l
l
l
A = one pole
l
l
l
l
l
l
l
l
l
l
B = two pole
C = four pole
l
l
l
l
l
l
l
l
Appropriate two digit circuit type
l
l
l
l
l
l
l
l
number from tables I, II, or III
l
l
l
Appropriate frame style code letter
l
l
l
l
l
l
from table IV
l
l
Appropriate rocker style code number
l
l
l
from table IV
l
l
Appropriate rocker color code letter
l
l
from table IV
Example: M3950/14A35F1W
