MIL-DTL-3786/35E
TABLE III. Switching characteristics and PIN's for type F construction. -
Continued.
PIN
Number
Number of
Type of
Termination
Switching
M3786/35-
of
positions
stops
Characteristics
poles
per pole
(S or NS)
072
2
2
Fixed
Printed circuit
S
073
2
3
Fixed
Printed circuit
S
074
2
4
Fixed
Printed circuit
S
075
2
5
Fixed
Printed circuit
S
076
2
6
Fixed
Printed circuit
S
077
4
2
Fixed
Printed circuit
S
078
4
3
Fixed
Printed circuit
S
079 1/
1
12
None
Solder lug
NS
080 1/
1
12
None
Printed circuit
NS
081 1/
1
12
None
Solder lug
S
082 1/
1
12
None
Printed circuit
S
083
3
2
Fixed
Solder lug
NS
084
3
3
Fixed
Solder lug
NS
085
3
4
Fixed
Solder lug
NS
086
6
2
Fixed
Solder lug
NS
087
3
2
Fixed
Printed circuit
NS
088
3
3
Fixed
Printed circuit
NS
089
3
4
Fixed
Printed circuit
NS
090
6
2
Fixed
Printed circuit
NS
091
3
2
Fixed
Solder lug
S
092
3
3
Fixed
Solder lug
S
093
3
4
Fixed
Solder lug
S
094
6
2
Fixed
Solder lug
S
095
3
2
Fixed
Printed circuit
S
096
3
3
Fixed
Printed circuit
S
097
3
4
Fixed
Printed circuit
S
098
6
2
Fixed
Printed circuit
S
1/ Continuous rotation.
TABLE IV. Switching characteristics.
Code
Switching
Type
Shaft
letter
characteristics
of stops
Type
A
Nonshorting
Fixed
Flatted
B
Shorting
Adjustable
Flatted
C
Nonshorting
Adjustable
Flatted
D
Shorting
Fixed
Flatted
E
Nonshorting
Fixed
Slotted
F
Shorting
Adjustable
Slotted
G
Nonshorting
Adjustable
Slotted
H
Shorting
Fixed
Slotted
