MIL-DTL-3786/35E
Example B: Flux sealed switches:
M3786/35-
A
G
AF
Switching characteristics and
type of stops (see table IV)
Type construction, low level capability, shaft
grounding, temperature life characteristic,
and shock type (see table V)
Angle of throw, poles per deck, and number of
positions per pole (see table VI)
PIN M3786/35-AGAF identifies a rotary switch with fixed stops, nonshorting switching characteristics, a
flatted shaft, printed circuit terminals, that is explosion proof, flux proof, closed construction, without
sealed shaft and panel seal, 30° angle of throw, 1 pole per deck, and 7 positions per pole and has low
level switching capabilities with a grounded shaft.
TABLE III. Switching characteristics and PIN's for type F construction.
PIN
Number
Number of
Type of
Termination
Switching
M3786/35-
of
positions
stops
Characteristics
poles
per pole
(S or NS)
001
1
2 through 12
Adjustable
Solder lug
NS
002
2
2 through 6
Adjustable
Solder lug
NS
003
4
2 through 3
Adjustable
Solder lug
NS
004
1
2 through 12
Adjustable
Printed circuit
NS
005
2
2 through 6
Adjustable
Printed circuit
NS
006
4
2 through 3
Adjustable
Printed circuit
NS
007
1
2
Fixed
Solder lug
NS
008
1
3
Fixed
Solder lug
NS
009
1
4
Fixed
Solder lug
NS
010
1
5
Fixed
Solder lug
NS
011
1
6
Fixed
Solder lug
NS
012
1
7
Fixed
Solder lug
NS
013
1
8
Fixed
Solder lug
NS
014
1
9
Fixed
Solder lug
NS
015
1
10
Fixed
Solder lug
NS
016
1
11
Fixed
Solder lug
NS
017
1
12
Fixed
Solder lug
NS
018
2
2
Fixed
Solder lug
NS
019
2
3
Fixed
Solder lug
NS
020
2
4
Fixed
Solder lug
NS
021
2
5
Fixed
Solder lug
NS
022
2
6
Fixed
Solder lug
NS
023
4
2
Fixed
Solder lug
NS
024
4
3
Fixed
Solder lug
NS
6
