MIL-DTL-15743E
4.4 1.3 Sampling for group B inspection. As a minimum, the contractor shall randomly select a
sample quantity from each lot of completed enclosed switches in accordance with table VI and inspect
them in accordance with table V in the order shown. The sample quantity shall be selected from
inspection lots that have passed group A inspection. If one or more defects are found in any sample, the
entire lot represented by the sample shall be rejected. If a lot is rejected, the contractor has the option of
screening 100 percent of the lot for the defective characteristic(s) or providing a new lot which shall be
inspected in accordance with the sampling plan contained herein. The contractor shall maintain for a
period of 3 years after contract completion all records of inspections, tests, and any resulting rejections.
4.5 Packaging inspection. Sample packages and packs and the inspection of the packaging, packing
and marking for shipment and storage shall be in accordance with the requirements of section 5 and the
documents specified therein.
TABLE IV. Classification of defects.
Categories
Defects
Critical:
None defined.
Major
101
Symbol not as specified.
102
Parts missing, damaged, nonconforming, improperly
fitted, or assembled.
103
Enclosure not as specified.
104
Light indicators/fuses not as specified; not mounted and
oriented as specified; not marked as specified.
105
Switch not type specified; not mounted and oriented as
specified; not marked as specified.
106
Dimensions not as specified.
107
Evidence of drilling, countersinking, and tapping after
plating or application of finish.
108
Materials less than minimum requirements;
evidence of unauthorized materials used; evidence of
cracks, splits, seams, or pitting.
109
Threads nonconforming, form not as specified, not to
size, missing, chipped, crossed, stripped, or damaged.
110
Terminal screws and lockwashers missing, damaged or
nonconforming.
111
Sharp corners of components not rounded as required.
112
Plating, when specified nonconforming, missing, or
incomplete; not smooth or uniform, evidence of peeling,
nonadherent or uncoated areas; evidence of oxide
scale or rust.
113
Wire, wiring methods not as specified.
114
Mounting characteristics not as specified.
115
O-rings missing; damaged; not lubricated as required.
116
Identification/information plates missing, damaged or
nonconforming; not secured and positioned as required.
Minor
201
Preservation, packaging, and packing not as specified.
202
Marking and manufacturer's identification, missing,
incorrect, illegible, not permanent, or not located as
specified.
11
