MIL-DTL-15743-17 Switch, Rotary, Enclosed, Submersible \(15 Feet\), Contact Maker, Six Pole, Two-Position, Spring-Return, 125 Volts Alternating Current, 10 Ampere, Symbol 2638.1

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11


MIL-DTL-15743/17B
A. T Knob. 06
B. Star Knob. 07
(same as 06, except as shown)
C. Square Knob. 08
D. Crown Knob. 09
(same as 06, except as shown)
(same as 06, except as shown)
FIGURE 6. Knobs. 06, 07, 08, 09
