MIL-PRF-8805/99H
Part or Identifying number (PIN): See tables III and IV.
Application information: Bushing O-ring seal (applicable to units with panel seal) has the potential of
stretching and rolling-over onto the flat "D" section of the threaded mounting bushing as the dress bezel
ring is installed, causing an improper seating of the O-ring. It is recommended that silicone grease be
applied to the O-ring seal in the dress bezel prior to installation to prevent this problem.
TABLE I. Electrical ratings.
Sea level
70,000
28 V dc
feet
Load
115 V ac, 400 Hz
28 V dc
(amperes)
(amperes)
2.0
Resistive
2.0
1.5
Inductive
1.5
Lamp
0.5
0.5
TABLE II. Qualification inspection (group submission).
Basic
Other switch
Extent of
Inspection
Switch
Samples
approval
Qualification
M8805/99-029
Two sample units each of
Inspection
M8805/99-006, and -015:
(All sample units)
Table of MIL-PRF-8805
Visual and mechanical
groups 1 through VIII
Vibration
inclusive
Shock
Operating characteristics
All
Two sample units each of
M8805/99-061:
Visual and mechanical
Solderability
Terminal strength
Operating characteristics
6
