MIL-PRF-8805/96E
TABLE I. Electrical ratings.
Loads
28 V dc
115 V ac, 60 Hz
Resistive
5.0 amperes
5.0 amperes
Inductive
2.0 amperes
2.0 amperes
Military part numbers: See table II.
TABLE II. Part numbers and characteristics.
Part number
Plunger
Circuit
Case
Hex
Enclosure
M8805/96
cap color
characteristics
color
nut
design
-001
Red
SPST-NO
Clear
2/
1 (unsealed)
-002
Black
SPST-NO
Clear
2/
1 (unsealed)
-003
Red
SPST-NC
Clear
2/
1 (unsealed)
-004
Black
SPST-NC
Clear
2/
1 (unsealed)
-005
Red
SPST-NO
Black
1/
1 (unsealed)
-006
Black
SPST-NO
Black
1/
1 (unsealed)
-007
Red
SPST-NC
Black
1/
1 (unsealed)
-008
Black
SPST-NC
Black
1/
1 (unsealed)
-009
Red
SPST-NO
Clear
2/
2 (dust tight)
-010
Black
SPST-NO
Clear
2/
2 (dust tight)
-011
Red
SPST-NC
Clear
2/
2 (dust tight)
-012
Black
SPST-NC
Clear
2/
2 (dust tight)
-013
Red
SPST-NO
Black
1/
2 (dust tight)
-014
Black
SPST-NO
Black
1/
2 (dust tight)
-015
Red
SPST-NC
Black
1/
2 (dust tight)
-016
Black
SPST-NC
Black
1/
2 (dust tight)
1/ MS25082-C14 or equivalent with black finish. Alternative base metals and protective
finishes, as approved by the qualifying activity, may be utilized for hardware material.
2/ MS25082-C14 or equivalent. Alternative base metals and protective finishes, as approved by
the qualifying activity, may be utilized for hardware material.
3
