MIL-PRF-8805/95J
TABLE I . PIN and characteristics.
PIN M8805/95-
Button color
Case color
Mounting nut
001
MS25082-C14 2/
Black
Clear
MS25082-C14 2/
002
Red
Clear
MS25082-B14
003
Black
Black
MS25082-B14
004
Red
Black
1/ PIN M8805/95-005 has been canceled without replacement.
2/ Alternative base metals and protective finishes, as approved by the
qualifying activity, may be utilized for hexagon nut material. Dimensions
shall be in accordance with the referenced hardware specifications.
Qualification inspection:
Group submission: See table I I .
TABLE I I . Qualification inspection group submission.
Switches for testing
Examination or test
Extent of
approval
Qualification
inspection table of
MIL-PRF-8805:
M8805/95-001
Group I All samples
Group II 4 samples
Group IV 2 samples
Group V 2 samples
Group VI 4 samples
All
Group VII 8 samples
Qualification
inspection table of
M8805/95-004
MIL-PRF-8805:
Group I All samples
Group IV 2 samples
Referenced documents. In addition to MIL-PRF-8805, this document references the following:
MIL-STD-202
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
