MIL-PRF-8805/93E
TABLE III. Qualification inspection.
Extent of
Examination or test
Test sample
approval
All sample units for groups II through
Group I (14 sample units).
V, plus I each of any type II unit
and any type III unit
Visual and mechanical examination
Operating characteristics
Group II (4 sample units).
2 sample units of each of the following:
Strength of actuating means
M8805/93-002 or 003
Strength of mounting bushing
and
Thermal shock
M8805/93-027 or 028
Vibration
Shock (specified pulse)
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
Marking visibility
Group III (2 sample units).
1 sample unit of each of the following:
M8805/93-002 or 003
and
Salt spray (corrosion)
M8805/93-027 or 028
All PIN's
Visual and mechanical examination
Marking visibility
Group IV (4 sample units).
Contact resistance
2 sample units of each of the following:
Low temperature operation 1/
M8805/93-002 or 003
Mechanical endurance at low
and
temperature 2/
M8805/93-027 or 028
Mechanical endurance at high
temperature 1/
Contact resistance
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
Group V (2 sample units).
1 sample unit of each of the following:
M8805/93-002 or 003
and
Electrical endurance
M8805/93-027 or 028
Sea level Inductive load, dc
Operating characteristics
1/
Test one M8805/93-002 or 003, and one M8805/93-027 or 028
2/
Same sample units as for low temperature operation.
