MIL-PRF-8805/92D
In qualification inspection table after electrical endurance the dielectric withstanding voltage points
of application between all unconnected terminals of the same pole are not applicable.
Mechanical endurance: 100,000 cycles.
Lever lock switches shall be tested for 100,000 cycles (at room ambient conditions) with the lever
being pulled to its fully extended position and then permitted to return to its fully retracted position by
spring action without operation of the switches. The cycling rate for this test shall be 60 cycles per
minute maximum. In addition to this test, the lever lock switches shall receive a normal mechanical
endurance test of 100,000 cycles of operation with the lever lock mechanism held in its fully
extended position continuously throughout the test.
Electrical endurance: 25,000 cycles.
Electrical ratings: See table I.
Qualification inspection (group submission): See table II.
Part or Identifying Number (PIN): See table III.
Circuit configuration: See table IV.
TABLE I . Electrical ratings.
Load
Sea level
50,000 feet
28 V dc
115 V ac, 60 Hz
28 V dc
amperes
amperes
amperes
Resistive
5
5
5
Inductive
3
5
2.5
Lamp
2.4
1.5
2.4
4
