MIL-PRF-8805/48H
TABLE II. Electrical ratings.
Load
Rating
Sea level 28 V dc
50,000 ft 28 V dc
code
Resistive
Inductive
Motor
Resistive
Inductive
(amperes)
(amperes)
(amperes)
(amperes)
(amperes)
A
5
3
4
5
2
B
10
6
6
10
3
C
15
10
5
15
10
TABLE III. PIN and characteristics.
Electrical
rating code
Circuit
PIN
(table II)
MS21320-1
A
DPDT
MS21320-2
A
DPDT
MS21320-3
B
DPDT
MS21320-4
B
DPDT
MS21320-5
C
2 circuit
MS21320-6
C
2 circuit
MS21320-7
C
4 circuit
MS21320-8
C
4 circuit
NOTE: MS21320 was superseded by
MIL-PRF-8805/48; the MS21320 Part
Numbers (PINS) were retained.
Qualification inspection:
Group submission: See table IV.
Group A inspection:
Seal test: Only watertight test shall be performed.
