MIL-PRF-8805/47G
TABLE I. Operating characteristics. 1/
A
Minimum
Maximum
B
Minimum
Actuating
Operating
Maximum
release
differential
Maximum
PIN
overtravel
force
position
Free
force
travel
pretravel
position
Inch
Inch
Inch
Inch
oz
oz
Inch
MS25011-1 2/
.600
.065
.53
.020
.010
16 ±8
4
MS25011-2 2/
.610
.085
.53
.020
.010
25 ±3
4
.790
.065
.72
.020
.010
16 ±6
4
MS25011-3 3/
.610
.085
.53
.020
.010
25 ±3
4
MS25011-4
1/ ±20 percent variation from specified values acceptable after test.
2/ MS25011-1 and MS25011-2 - inactive for new design.
3/ MS25011-3 has been canceled without replacement."
NOTE: MS25011 was superseded by MIL-PRF-8805/47; the MS25011 Part Numbers (PINS) were
retained.
TABLE II. Electrical ratings.
Current capacity (amperes)
PIN
Load
115 V ac, 60
120 V dc
28 V dc
Hz
MS25011-1
Resistive
25
1
1
MS25011-2
Inductive
10
1
.5
MS25011-4
Resistive
25
1
.5
Inductive
8
1
.5
TABLE III. Group submission.
Basic
Other
Extent of
Examination
switch 1/
Switch
approval
or test
Qualification inspection table of
MS25011-1 2/
MS25011-2 2/
MIL-S-8805 (except operating
(2 sample units)
and
characteristics in group VI shall
All
1. Visual and mechanical
be tested immediately
MS25011-4
examination
(all sample units)
preceding short circuit, rather
2. Operating characteristics
than as the final test).
1/ MS25011-1 and MS25011-2 are inactive for new design.
2/ Qualification testing of MS25011-4 may be waived if testing is performed on MS25011-2.
NOTE: MS25011 was superseded by MIL-PRF-8805/47; the MS25011 Part Numbers (PINS) were
retained.
