MIL-PRF-8805/27E
TABLE IV. Inspection of product for delivery.
Inspection
Visual and mechanical 1/
Operating characteristics 2/
Contact bounce (when specified) 2/
Dielectric withstanding voltage
Contact resistance (when applicable) 2/
1/ In-process inspection may be used to satisfy the
dimensional requirements.
2/ Do not exceed 6 V dc, or peak ac, 10 milliamperes
during inspection of MS25253-8 through 13..
TABLE V. PIN's.
Description
Sugested application 2/
PIN 1/
MS25253-
Power
Electronic
Low
Contacts
Circuit
Rating
Terminals
Circuit
logic
level
maximum
Type
Strength
(lbs.)
X
20
Screw
Table I (10 AMPS)
1
Silver
SPDT
X
"
"
"
2
SPNO
"
X
"
"
"
3
SPNC
"
X
"
Solder
"
5
SPDT
"
X
"
"
"
6
SPNO
"
X
"
"
"
7
SPNC
"
X
X
X
"
Screw
Table II (1 AMP)
8
3/
SPDT
Gold
X
X
X
"
"
"
9
3/
SPNO
"
X
X
X
"
"
"
3/
SPNC
10
"
X
X
X
"
Solder
"
11
3/
SPDT
"
X
X
X
"
"
"
3/
SPNO
12
"
X
X
X
"
"
"
13
3/
SPNC
"
1/ MS25253-4 is canceled, use MS25253-1.
2/ Application information
Power circuits Those electrical loads where the voltage and current exceed the minimum arcing
conditions of the contact material. As a general rule, application loads in excess of 8 volts, 0.5 amperes
are considered power circuits.
Electronic logic circuits Those electrical loads in which the applied voltage is less than the arcing
voltage and greater than the non-arcing application loads in excess of 0.5 volts are considered logic
level circuits.
Low level circuits - Those electrical loads in which the applied voltage is less than the softening
voltage of the contact material. As a general rule, application loads less than .08 volts are considered
low level circuits.
3/ MS25253-8 through 13 have two levels of capabilities. However, switches previously tested or used
above 10 milliamperes resistive at 6 V dc max or peak ac are not recommended for use in electronic
logic or low level application.
