MIL-PRF-8805/27E
Quality assurance:
Qualification inspection: See table III
Inspection of product for delivery: See table IV.
Part or Identifying Number (PIN): See table V
TABLE I . Electrical ratings silver contacts (MS25253-1, -2, -3, and 5 through 7).
Sea level
50,000 feet
Load
28 V dc
115 V ac, 60 Hz
28 V dc
115 V ac, 60 Hz
Amperes
Amperes
Amperes
Amperes
Resistive
10
10
10
10
Inductive
10
10
6
10
Motor
6
3
----
----
TABLE I I . Electrical ratings gold contacts (MS25253-8 through 13).
Sea level and 50,000 feet
Sea level
Load
Power circuit
Electronic logic
Low level 1/
28 V dc
circuit 5 V dc
30 millivolts
Amperes
Amperes
Amperes
Resistive
1.0
0.01
0.01
Inductive
0.5
----
----
1/ 30 millivolts max dc or peak ac.
4
