MIL-PRF-8805/18G
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Enclosure design: 1 (unsealed).
Temperature characteristic: 1 (-55°C to +85°C).
Shock type: Method 213, test condition A, MIL-STD-202 (50 g).
Vibration grade: 1 (10 to 500 Hz)
Weight: .05 pound maximum.
Operating characteristics:
Actuating force ................. 3.50 pounds maximum
Movement differential ....... .036 inch maximum.
Pretravel ........................... .075 inch maximum.
Overtravel ......................... .015 inch minimum.
Strength of actuating means: 25 pounds.
Terminal strength: 5 pounds.
Mechanical endurance: 100,000 cycles.
Electrical endurance: 50,000 cycles.
Electrical ratings: See table I.
Part number: MS253561. (MS25356 was superseded by MIL-PRF-8805/18; the MS25356-1 Part
Number (PIN) was retained.)
TABLE I. Electrical ratings.
Sea level
Load
28 V dc
115 V ac, 400 Hz
amperes
amperes
Resistive
15
15
Inductive
10
15
Lamp
10
6
3
