INCH-POUND
MIL-PRF-8805/111A
31 October 2001
SUPERSEDING
MIL-PRF-8805/111
21 October 1983
PERFORMANCE SPECIFICATION SHEET
SWITCH, ASSEMBLIES, SENSITIVE, TRIGGER,
7 AMPERES, UNSEALED
This specification forms a part of MIL-PRF-8805, dated 23 January 1998, and is
approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification and MIL-PRF-8805.
Type
Dimension A
Side cover material
.641 ±.016
Aluminum or equivalent (black anodized
Type I
.762 +.000
Polyester or equivalent (color: black)
Type II
-.025
FIGURE 1. Configurations and dimensions.
AMSC N/A
1 of 6
FSC 5930
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
