MIL-PRF-8805/106B
TABLE I. Electrical ratings and PIN's
Load
PIN M8805/106-
Sea level, 28 V dc
01
02
Amperes
Amperes
Resistive
2.0
1.0
Inductive
1.0
0.5
Lamp
0.25
-------
Qualification:
Group submission: See table I I .
Group A inspection: Do not exceed low level electrical ratings during any testing of M8805/106-02.
TABLE I I . Group submission qualification inspection.
PIN'S
Number of sample units
Examination or test
M8805/106-01
18
Qualification inspection table of MIL-PRF-8805
Group I, VII, and X of MIL-PRF-8805 qualification
M8805/106-02
6
inspection table
Application note: Environmental contamination in the application can adversely affect the ability of the
M8805/106 -02 switch to provide consistent performance on low level loads. Protection from
environmental contamination can be accomplished by providing an appropriately sealed enclosure.
Referenced documents. In addition to MIL-PRF-8805, this document references the following:
MIL-STD-202
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Custodians:
Preparing activity
DLA CC
Navy EC
Air Force 11
DLA CC
(Project 5930-2006-072)
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil/
3
