MIL-PRF-8805/104D
TABLE I. Electrical ratings.
28 V dc
115 Vac, 400 Hz
Load
Sea level
80,000 ft.
Sea level
80,000 ft.
(amperes)
(amperes)
(amperes)
(amperes)
Resistive
7
7
1
1
Inductive
3
3
1
1
Motor
4
4
1
1
Lamp
2
2
1
1
Qualification and group C retention of qualification:
Group submission: See table III.
Group C retention of qualification: Nondestructive wire exit test is applicable (6 sample units).
TABLE III. Qualification and group - C tests (group submission).
Examination or test
Samples
Extent of approval
Qualification inspection table
M8805/104-002
of MIL-PRF-8805 1/
(12 units)
Visual and mechanical examination
M8805/104-001, -004
Operating characteristics
(2 units each)
M8805/104-001, -004
Wire exit test 2/
(2 units each with potting,
All
2 units each without potting)
Temperature cycling 3/
M8805/104-001
(in accordance with table I)
(2 units)
Marking test 4/
M8805/104-001
(2 units)
1/ Case and plunger grounding test to be accomplished before and after mechanical
endurance.
2/ Destructive test is applicable in initial qualification testing only.
3/ Applicable in qualification testing only.
4/ Following immersion, the switch shall also be subjected to terminal strength, insulation
resistance, dielectric withstanding voltage, operating characteristics, and seal tests.
