MIL-PRF-83504/9C
Dimensions and configuration: See figure 1 and table I.
Seal: Sealed base. No top seal.
Switch position and setting identification: See figure 1.
Orientation: See figure 1.
Tape top seal: Not provided
Operating force: 6-32 ounces.
Electrical ratings:
10 mA maximum at 50 mV, switching (resistive load)
100 mA maximum at 6 V dc, switching (resistive load)
25 mA maximum at 24 V dc, switching (resistive load).
Application note: In applications where the switch will mate with sockets or with panel boards, the user
should consider the compatibility of the mating terminals with respect to finished and mechanical
configurations.
Part or Identifying Number (PIN): M83504/09- (and dash number from table I).
TABLE I. Dash numbers and characteristics
Dash
Number
Dimension
number
of stations
"A" inches (mm)
021
2
.380
(9.65)
022
3
.580
(14.73)
023
4
.780
(19.81)
1/ PIN's M83504/09-002, -003, -004 (switches with gold
finish terminals have been cancelled without
replacement
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5930-1128-08)
DLA - CC
Review activities:
Army - AR, AV, MI
Navy - AS
Air Force - 99
3
