MIL-PRF-22710/30A
.032 (.81) minimum Thk PCB;
.064 (1.63) minimum dia. solder hole connections
Module B
Truth table 2
Circuit Configuration 2
36 Indexing
Common C
Dial
Conn to:
Reads
1
2
4
8
0
1
2
3
4
5
6
7
8
9
FIGURE 1. Terminal design and circuit configuration - Continued.
