MIL-PRF-22710/23D
REQUIREMENTS:
Dimensions and configuration: See figure 1 and 2.
Construction: D.
Angle of Throw: 30 , 36 and 45 indexing, also octal or binary codes.
Temperature-life characteristic: D, test loads as shown in table I.
TABLE I. Electrical test load.
Test of condition
Resistive
At atmospheric pressure
0.125 A
28 V dc, 115 V ac
At reduced barometric pressure
0.05 A
28 V dc, 115 V ac
Dry circuit
10 mA
50 mV
Vibration grade: 3 (15g, 10 - 2,000 Hz).
Shock types: M (100 g's)
Altitude rating: C (70,000 feet).
Terminal design: See figure 3 and table III.
Contact resistance:
Initial: 50 milliohms, maximum.
Following life (rotational): 70 milliohms, maximum.
Luminace: Illuminated switches only as shown in table II.
TABLE II. Luminance.
Rating
Switch
Lamp
Brightness
filter
Volts
Ampere
MS90452-6833
Clear
5
0.60
1.50 .75 foot-lamberts
MS90452-6833
Red
5
0.60
.70 .50 foot-lamberts
Rotational torque: 20 ounce minimum to 40 ounce maximum.
Seal: Method II, when specified in table I.
Dielectric withstanding voltage: 1,000 volts rms, at atmospheric pressure and 450 volts, rms, at
reduced barometric pressure applied between the switch terminals and termials to case.
Sand and dust: Applicable.
Explosion: Applicable.
Life (rotational): Test condition G, method 206 of MIL-STD-202.
EMI/RFI shielding: Applicable when specified (see table III).
Military part number: M22710/23- (dash number from table III).
