MIL-PRF-22710/20D
MODULE A, A1, A2 or A3
MODULE B, B1, B2 or B3
TRUTH TABLE
LEAD
COLOR
(Circuit configuration 1)
C
WHT.BRN
36 INDEXING
O
BLACK
DIAL
COMMON C
1
BROWN
MARKING
CONN. TO::
2
RED
0
0
3
ORANGE
1
1
4
YELLOW
2
2
5
GREEN
3
3
6
BLUE
4
4
7
VIOLET
5
5
8
GREY
6
6
9
WHITE
7
7
8
8
9
9
Figure 3. Module and circuit configuration.
