MIL-PRF-22710/20D
Dimensions
No. of
B
C
D
A
0.03 (0.76)
stations
inches
mm
inches
mm
inches
mm
inches
mm
1
1.26
32.00
1.09
27.69
0.9
22.86
0.92
23.37
2
1.76
44.70
1.59
40.39
1.4
35.56
1.42
36.07
3
2.26
57.40
2.09
53.09
1.9
48.26
1.92
48.77
4
2.76
70.10
2.59
65.79
2.4
60.96
2.42
61.47
5
3.26
82.80
3.09
78.49
2.9
73.66
2.92
74.17
6
3.76
95.50
3.59
91.19
3.4
86.36
3.42
86.87
7
4.26
108.20
4.09
103.89
3.9
99.06
3.92
99.57
8
4.76
120.90
4.59
116.59
4.4
111.76
4.42
112.27
9
5.26
133.60
5.09
129.29
4.9
124.46
4.92
124.97
10
5.76
146.30
5.59
141.99
5.4
137.16
5.42
137.67
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only and are based upon
1 inch = 25.4 mm.
3. Unless otherwise specified, tolerance is .010 (.25 mm).
4. Allowance for lighting terminals for externally replaceable lamps.
FIGURE 1. Style SRPC20 switch and panel cutout (unshielded switch) - Continued.
