MIL-PRF-22710/11F
No. of
Dimensions
Modules
D
B
.896
1.079
1
(22.76)
(27.41)
1.398
1.581
2
(35.51)
(40.16)
1.900
2.083
3
(48.26)
(52.91)
2.402
2.585
4
(61.01)
(65.66)
2.904
3.087
5
(73.76)
(78.41)
3.406
3.589
6
(86.51)
(91.16)
3.908
4.091
7
(99.26)
(103.91)
4.410
4.593
8
(112.01)
(116.66)
4.912
5.095
9
(124.76)
(5.597)
5.414
5.597
10
(137.52)
(142.16)
NOTES:
1. Black matte finish over silver - for all surfaces exposed from front of panel.
2. No color coating to be applied over silver in this area (both corners).
3. No paint applied to surface, .25/.35 diameter.
4. .062 .002 DIA drilled out holes.
5. Minimum silvered surface, measure, measured from mounting surface.
FIGURE 2. RFI Shielded switch and panel cut-out
3
