MIL-PRF-22710/11F
Number of
Dimensions
stations
A (MAX)
B
C
D
1
1.50 ( 38.10)
1.075 ( 27.31)
0.870
( 22.10)
0.890
( 22.61)
2
2.00 ( 50.80)
1.575 ( 40.01)
1.370
( 34.80)
1.390
( 35.31)
3
2.50 ( 63.50)
2.075 ( 52.71)
1.870
( 47.50)
1.890
( 48.01)
4
3.00 ( 76.20)
2.575 (65.41)
2.370
( 60.20)
2.390
( 60.71)
5
3.50 ( 88.90)
3.075 (78.11)
2.870
( 72.90)
2.890
( 73.41)
6
4.00 (101.60)
3.575 ( 90.81)
3.370
( 85.60)
3.390
( 86.11)
7
4.50 (114.30)
4.075 (103.51)
3.870
( 98.30)
3.890
( 98.81)
8
5.00 (127.00)
4.575 (116.21)
4.370
(111.00)
4.390
(111.51)
9
5.50 (139.70)
5.075 (128.91)
4.870
(123.70)
4.890
(124.21)
10
6.00 (152.40)
5.575 (141.61)
5.370
(136.40)
5.390
(136.91)
NOTES:
1. Dimensions are in inches.
2. Millimeters are in parentheses.
3. Metric equivalents are given for general information only and are based upon
1 inch = 25.4 mm.
4. Unless otherwise specified, tolerance is 0.010 (0.25).
5. Applicable to illuminated switches only. Top relampable switch shown. Allowance
for lighting terminals for externally replaceable lamps, when internal lighting is
specified.
2
