MIL-DTL-9395/43C
Pulsation amplitude: A (0 percent).
Pulsation frequency: A (0 Hz).
Pressure rise: A (less than 100 lbf/in2).
Dielectric withstanding voltage (at reduced barometric pressure): Applicable at 350 V rms.
Connector torque:
Electrical connector: Applicable.
Pressure port mounting torque: 100 inch-pounds maximum.
Flame test: Applicable.
Explosion: Applicable.
Qualification:
Single submission: Restricted to switch submitted.
Group submission: See table V.
Part number: Part numbers shall be assigned as follows:
Example :
M9395/43-
A
2-
Z+
"M" prefix and specification sheet number.
Configuration and pressure setting mode.
Code A of table I.
High-pressure setting,
Code "2" of table II (2600 lbf/in2)
and Code "-" of table III (+75 lbf/in2).
Low-pressure setting,
Code "Z" of table II (2400 lbf/in2) and
Code "+" of table III (+50 min 5 lbf/in2).
Part number M9395/43-A2-Z+ describes a switch of configuration "A" which actuates on increasing
pressure at 2675 lbf/in2 maximum and deactuates on 2450 lbf/in2.
Part number M9395/43-BVRST describes a switch of configuration "B" which actuates on increasing
pressure at 2075 ±100 lbf/in2 and with a deadband value of 400 to 425 lbf/in2.
NOTE: Design limitations (actuation values and tolerances, deadband and deactuation values and
tolerances) should be coordinated with manufacturer(s) listed on the QPL for this specification sheet
before specifying a particular "M" number. The fact that operating characteristics can be coded does not
necessarily mean that it can be manufactured or acquired.
3
