MIL-DTL-83731/22C
TABLE II. Circuit for switching characteristic.
Circuit with toggle in
Locking
Circuit
Keyway side
Opposite
arrangement
number
(down position)
Center
keyway side
(see figure 3)
(up position)
71
A
1-2
ON
7-8
OFF
2-3 ON
8-9
4-5
10-11
5-6
11-12
73
D
1-2
ON
7-8
NONE
2-3 ON
8-9
4-5
10-11
5-6
11-12
76
F
1-2
MOM-ON
7-8
NONE
2-3 ON
8-9
4-5
10-11
5-6
11-12
77
E
1-2
MOM-ON
7-8
OFF
2-3 MOM-ON 8-9
4-5
10-11
5-6
11-12
81
K
1-2
MOM-ON
7-8
OFF
2-3 ON
8-9
4-5
10-11
5-6
11-12
82
A
1-2
ON
7-8
2-3 ON 8-9
2-3 ON
8-9
4-5
10-11
4-5
10-11
5-6
11-12
FIGURE 3. Locking arrangements.
TABLE III. Termination type.
Solder lug
1
Printed circuit
2
6
