MIL-DTL-5423/15H
REQUIREMENTS
Dimensions and configuration: See figure 1.
Silicon rubber: Grade 50 per A-A-59588.
Watertightness: MIL-STD-108, table I.
Endurance: 500,000 operations, see MIL-DTL-5423. Minute cracks after life test, which do not permit leakage,
shall not be cause for rejection.
Color: See table I.
Part or Identifying Number (PIN): See figure 1 or table I.
TABLE I. Colors.
Former part number
Part Number
Color
identification
SM-C-96099
M5423/15-01
Gray
SM-C-105369
M5423/15-02
Black
SM-C-544237
M5423/15-03
Black
SM-C-627674
Qualification: First Article Testing in accordance with MIL-DTL-5423.
The margins of this specification are marked with vertical lines to indicate where modifications were made. This was
done as a convenience only and the Government assumes no liability whatsoever for any inaccuracies in these
notations. Bidders and contractors are cautioned to evaluate the requirements of this document based on the entire
content irrespective of the marginal notations.
Reference Documents:
MIL-DTL-5423
MIL-STD-108
A-A-59588
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - AS
Air Force - 85
(Project 5930-2008-071)
DLA CC
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil.
