INCH-POUND
MIL-DTL-5423/12D
17 February 2009
SUPERSEDING
MIL-DTL-5423/12C
4 February 2008
DETAIL SPECIFICATION SHEET
BOOT, DUST AND WATER SEAL, TYPE A (FOR TOGGLE SWITCHES),
STYLE 9 (FIVE-HOLE MOUNTING, THROUGH)
This specification sheet is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and MIL-DTL-5423.
Inches
mm.
Inches
mm.
.031
.79
.390
9.91
1.14
.562
14.27
.045
.062
1.57
.650
16.51
.156
3.96
.670
17.02
.200
5.08
.750
19.05
.210
5.33
.937
23.80
.937±.031
.750
.390
.SHALL PASS OVER .200 DIA PIN
AND FIT SNUGLY ON .210 DIA PIN
.562
±.031
.062
.045
.SHALL PASS OVER .650 DIA PIN
AND FIT SNUGLY ON .670 DIA PIN
(FOR DEPTH OF .156 MIN)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.015.
FIGURE 1. Dimensions and configuration boots type A, style 8.
FSC 5930
AMSC N/A
