MIL-DTL-3786/32C
Part number 1/ : The military part number shall consist of the prefix "M3786/32-" followed by one
character each from tables II, III, and IV, as applicable. An example is shown below:
Example:
M3786/32- C
K
G
Military designator and
specification sheet no.
Construction type N, two decks,
both nonshorting (see table II).
Two poles per deck, 22.5
angle of throw (see table III)
Seven positions
(see table IV)
1/ Part numbers shall be used to identify only switches shown in figure 2. Switches not identified by part
numbers shall be procured in accordance with the ordering data of MIL-DTL-3786.
APPLICATION NOTE: To conserve material, space, and weight, the following is suggested:
(a)
Two-, three-, four-, five-, six-, seven-, eight-, nine-, ten-, eleven-, and twelve-position switches
with 15° angle of throw should be two poles per deck.
Two-, three-, four-, five-, and six-position switches with 15° angle of throw should be four poles
(b)
per deck.
Two-, three-, four-, five-, six-, seven-, eight-, nine-, and ten-position switches with 18° angle of
(c)
throw should be two poles per deck.
Two-, three-, four-, and five-position switches with 18° angle of throw should be four poles per
(d)
deck.
Two-, three-, four-, five-, six-, seven-, eight-, and nine-position switches with 20° angle of
(e)
throw should be two poles per deck.
Two-, three-, four-, five-, six-, seven-, and eight-position switches with 22.5° angle of throw
(f)
should be two poles per deck.
Two-, three-, and four-position switches with 22.5° angle of throw should be four poles per
(g)
deck.
Two-position and three-position switches with 30° angle of throw should be four poles per
(h)
deck.
Four-position switches with 30° angle of throw should be three poles per deck.
(i)
Five- and six-position switches with 30° angle of throw should be two poles per deck.
(j)
Two-, three-, four-, and five-position switches with 36° angle of throw should be two poles per
(k)
deck.
Two-, three-, and four-position switches with 45° angle of throw should be two poles per deck.
(l)
7
