MIL-DTL-24236/16G
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Enclosure design: All entrances to the switch cavity except through the actuator bushing shall be sealed by
fusion of glass-to-metal, metal-to-metal, or ceramic-to-metal.
Class: Class 4, except vibration of 10 g's.
Ambient temperature range: -65°F to 1,000°F.
Operating temperature: See table I.
Temperature adjustment: The threaded temperature adjusting screw (see figure 1) shall be so designed and
constructed that the operating temperature can be easily adjusted over the range 135°F to 900°F, without the use
of special tools. One revolution of the mechanism shall not change the operating temperature by more than 370°F.
Delivery temperature: Prior to delivery, switches shall be adjusted to operate at the applicable operating
temperature.
Temperature markings: The operating temperature setting of the switch shall be durably and legibly marked as
shown on figure 1.
TABLE I. Operating temperature.
Dash
Temperature
Dash
Temperature
number
setting
number
setting
°F
°F
Tolerance °F
Tolerance °F
±20
±20
525
135
135
525
±20
±20
535
180
180
535
550
215
±20
±20
215
550
600
240
240
600
±20
±20
650
250
250
650
±20
±20
675
300
300
675
±20
±20
700
325
325
700
±20
±20
725
400
400
725
±20
±20
750
425
425
750
±20
±25
825
450
450
825
±20
±25
900
500
500
900
Test tolerances: The allowable post test set point tolerance, should be referenced to the actual pretest set point.
Electrical ratings: 3 amperes (lamp) at 28 V dc.
Environmental test effect: Not applicable.
Weight: 6 ounces maximum, including terminal hardware.
Visual and mechanical examination: X-ray is applicable.
Solderability: Not applicable.
2
