MIL-DTL-21604/7C
TABLE I. Type designation and switching characteristics.
Maximum rotational
Approx.
No. of
Operating
Rotor
torque
Component
Style 1/
weight
designation 2/
sections
positions
(inch-pounds)
(ounces)
15
17
8
3
2
JR 304
S
30
17
3
3
2
JRM 300
S
1/ Style and type designations are synonymous for JR 304 and JRM 300, respectively.
2/ For rotor designation, see figure 2.
TABLE II. Qualification test sample.
Test number 1/
Sample switch
Test number
Sample switch
S2JR304
1
S2JRM300
1
S2JR304
2
S2JRM300
2
S2JR304
3
S2JRM300
3
S2JR304
4
S2JRM300
4
S2JR304
5
S2JRM300
5
S2JR304
6
S2JRM300
6
1/ Test numbers in accordance with table II of MIL-DTL-21604.
2/ For group qualifications, see 4.5.1.
