MIL-DTL-15743/5C
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 125 V ac, 0-10 ampere, 60 Hz.
Dimensions and configuration: See figures 1 through 8.
Wiring diagram: See figure 10.
Mounting dimensions: See figure 9.
Degree of enclosure: Submersible (15 feet).
Weight:
(a) Symbols 827.1 and 850.1 3 pounds maximum.
(b) Symbol 863 3 pounds maximum.
Designation and marking: See figure 10.
Identification data shall be as shown on figure 10. Unless otherwise specified in the ordering data,
ON-OFF switch action marking shall be as shown on figure 10 and all others shall be left blank.
Parts: The parts shown in table II and as specified in MIL-DTL-15743 shall be used in the
construction of the switches specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
Supersedes 1/
Military
Symbol
No. of poles and switching
part no.
no.
characteristics
Type
M15743/5-001
827.1
SPECIAL
1SRSS4-2
M15743/5-002
850.1
TPDT
1SR3C4-2
M15743/5-003
863
4PDT
1SR4B4-2
1/ From NAVSEA Drawing 9000-S6202-74207.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action marking, if required (see requirements).
9
