MIL-DTL-15743/5C
TABLE II. Parts list.
Quantity
M15743/5-
Item
Description
Material/
Remarks
no. 1/
specification
001
002
003
01
Switch, enclosed
-
See figure 1
(sym 827.1)
02
Switch, enclosed
-
See figure 1
(sym 850.1)
03
Switch, enclosed
-
See figure 1
(sym 863)
04
Enclosure
1
1
1
Brass,
See figure 2 & 3
MIL-E-24142/5
M24142/5-002
(modified)
05
O-ring
1
1
1
SAE-AS28775-010
----
06
Handle
1
1
1
Copper alloy
See figure 4
ASTM-B584
07
Shaft assembly
1
1
1
----
See figure 5
08
Shaft
1
1
1
Ni-Cu alloy of
See figure 6
QQ-N-281
09
Coupler
1
1
1
Brass,
See figure 7
ASTM-B36/B36M,
ASTM-B121/B121M
10
Coupler plate
1
1
CRES, or
See figure 8
equivalent
11
Wiring diagram
1
MIL-E-2036
See figure 10
12
Wiring diagram
1
MIL-E-2036
See figure 10
13
Wiring diagram
1
MIL-E-2036
See figure 10
14
Switch
1
Drawing 9000-
(type 1SRSS4)
S6202-74085
15
Switch
1
MIL-DTL-15291/3
M15291/3-011
(type 1SR3B4)
16
Switch
1
MIL-DTL-15291/3
M15291/3-012
(type 1SR4B4)
17
Identification plate
1
1
1
ASTM-B36/B36M,
See figure 11
ASTM-B121/B121M
1/ Numbers in circles shown on the figures are the same as the item numbers shown in
this table.
