MIL-DTL-15743/16B
TABLE II. Parts list.
Quantity
Item
Description
M15743/
Material/
Remarks
no. 1/
16-001
specification
01
Switch, enclosed
-
----
See figure 1
(sym 2637.1)
02
Enclosure
1
MIL-E-24142/5
M24142/5-002
Mod 2/
03
O ring seal
1
SAE-AS28775-012
----
04
Handle
1
Copper alloy 854 or
See figure 4
equivalent
05
Wiring diagram
3/ 1
MIL-E-2036
See figure 6a
06
Wiring diagram
3/ 1
MIL-E-2036
See figure 6b
07
Wiring diagram
3/ 1
MIL-E-2036
See figure 6c
08
Switch
1
MIL-DTL-21604/7
----
(type JRM 300)
09 thru
Identification plate
3/ 1 ea.
ASTM-B36/B36M,
See figure 7
16
ASTM-B121/B121M
1/ Numbers in circles shown on the figures are the same as the item numbers
shown in this table.
2/ Modified enclosure to change location of positioning pin and hole (see figures 2 and 3).
3/ See table III for switch-function marking and parts selection.
TABLE III. Switch function and parts selection data.
Parts selection
Switch function 1/
Identification
Wiring diagram
(see figure 7)
plate item no.
item no.
Blank
09
None
Whistle switch
10
07
Cease firing
11
06
More feed
12
05
Feed started
13
05
Emergency feed started
14
05
Start emergency feed
15
05
Aircraft contact
16
2/
1/ Switch function shall be as specified in the ordering data. When not specified,
or when enclosed switches are being ordered for stock in the supply system,
the switch function shall be blank (item 09).
2/ Wiring diagram shall be as specified in the ordering data.
