MIL-DTL-15743/16B
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 125 V ac, 0-10 ampere, 60 Hz.
Dimensions and configuration: See figures 1 through 5.
Wiring diagram: See figure 6.
Mounting dimensions: See figure 5.
Degree of enclosure: Submersible (15 feet).
Weight: 4 pounds maximum.
Designation and marking: See figures 7.
Identification data shall be blank as shown on figure 7. Unless otherwise specified in the
ordering data, switch action marking shall be as shown on figure 7. Switch function marking shall be
as shown in table III.
Parts: The parts shown in table II and as specified in MIL-DTL-15743 shall be used in the
construction of the switch specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
Supersedes 1/
Military
Symbol
part no.
no.
Type
Revision
Date
M15743/16-001
2637.1
S2JRM3-2
H
7/10/80
1/ From NAVSEA Drawing 803-74055.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action marking, if required (see requirements).
7
