MIL-PRF-8805/90G
TABLE I. Electrical ratings.
Sea level
50,000 feet
Load
28 V dc
115 V ac, 60 Hz
28 V dc
115 V ac, 60 Hz
(amperes)
(amperes)
(amperes)
(amperes)
Resistive
10
10
10
10
Inductive
6
10
6
10
Motor
6
3
---
---
TABLE II. Group submission.
Examination or test
Basic switch
Other switch samples
Extent of approval
M8805/90-002 and
Qualification inspection
M8805/90-003
table of MIL-PRF-8805,
M8805/90-001
(2 sample units each)
All
(all sample units)
groups I through VIII,
visual and mechanical
inclusive
examination
TABLE III. PIN's and characteristics.
PIN's
Terminals
Switching
M8805/90
characteristics
-001
NC, NO and Common
SPDT
-002
NO and Common
SPNO
-003
NC and Common
SPNC
The margins of this specification are marked with vertical lines to indicate where changes form the
previous issue were made. This was done as a convenience only and the Government assumes no liability
whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations
and relationship to the last previous issue.
Referenced Documents: In addition to MIL-PRF-8805, this document references the following :
MIL-STD-202
Custodian:
Preparing activity:
Navy - EC
DLA - CC
DLA - CC
(Project 5930-2007- 026)
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above
using the ASSIST Online database at https://assist.daps.dla.mil/
3
