MIL-PRF-8805/82E
TABLE II. Electrical ratings.
Sea level and 70,000 feet
PIN
Load
115 V ac, 400 Hz and 28 V dc
Amperes
M8805/82-001
Resistive
4
Inductive
3
1.5
Lamp
2
M8805/82-002
Resistive
.5
And
Inductive
.5
M8805/82-003
Lamp
Low level circuit test applicable
Qualification:
Group submission: See table III.
TABLE III. Qualification testing group submission.
Examination or test
Extent of
Sample
approval
(See qualification inspection table of MIL-PRF-
8805)
Groups I, II, III, VI, VII, and VIII.
M8805/82-001
Group VII test are required at sea level only.
Visual and mechanical examination
M8805/82-003
Group I
Visual and mechanical examination
Solderability
All
Operating characteristics
PINs
Group II
M8805/82-002
Thermal shock
Vibration
Dielectric withstanding voltage
Operating characteristics
QUALITY ASSURANCE:
Group A inspection:
Seal: Only the watertight test shall be performed, in Group A. Switches need not be removed from
underwater during the test.
M8805/82-002 and -003: Do not exceed low level electrical ratings during any testing.
Group B inspection: M8805/82-001 shall be submitted to the tests of the group B inspection table of
MIL-PRF-8805. In addition, M8805/82-002 shall be submitted to the tests of table IV.
