MIL-PRF-8805/76H
TABLE I. Electrical ratings.
Sea level, 28 V dc
70,000 feet, 28 V dc
Load
SPST
SPST
2 circuit
(NO or NC)
2 circuit
(NO or NC)
(amperes)
(amperes)
(amperes)
(amperes)
Resistive
8
5
8
5
Inductive
5
3
3
2
Motor
5
---
---
---
Lamp
1
---
---
---
TABLE II. PIN and terminal configurations.
Terminal
PIN
configuration
MS27257-1
Spade type
MS27257-2
Turret type
NOTE: MS27257 was superseded by MIL-PRF-8805/47; the MS27257
Part Numbers (PINS) were retained.
QUALIFICATION:
Group submission: See table III.
TABLE III. Group submission.
Extent of
PIN
Examination or test
approval
MS27257-1
Qualification inspection table of MIL-
PRF-8850
All
Visual and mechanical examination
MS27257-2
Terminal strength
(2 sample units)
Dielectric withstanding voltage
Operating characteristics
4
