MIL-PRF-8805/70L
Qualification:
Group submission: See table II.
Military Part or Identifying Number (PIN): See table III.
TABLE I. Electrical ratings.
Sea level and 70,000 feet
Load
28 Vdc
Resistive
4
Inductive
1
Lamp
2
TABLE II. Qualification.
Basic
Other switch samples
Extent of
Inspection
Switch
approval
M8805/70-033 through
Qualification inspection table
037, -039, -040
(2 sample units each):
M8805/70-038
of MIL-PRF-8805, groups I
All
(all sample units)
through IV inclusive
Visual and mechanical
(seal test not required)
inspection only
TABLE III. PIN's and configuration.
Resistive
Type of
Circuit
PIN 1/
Load
actuating
Terminals
Diagram
rating
mechanism
4 Amp
M8805/70-033
1
A
Wire leads - bottom
M8805/70-034
1
B
Wire leads - bottom
M8805/70-035
1
A
Wire lead - side
M8805/70-036
1
B
Wire lead - side
25,000
2
A
M8805/70-037
Wire leads - bottom
2
B
M8805/70-038
Wire leads - bottom
2
A
M8805/70-039
Wire lead - side
M8805/70-040
2
B
Wire lead - side
1/ PIN's 001 through 032 have been canceled without replacement.
