INCH-POUND
MIL-PRF-8805/7H
31 January 2006
SUPERSEDING
MIL-PRF-8805/7G
19 September, 2000
PERFORMANCE SPECIFICATION SHEET
SWITCHES, PUSH, MOMENTARY, 2 CIRCUIT OR SPST (10 AMPERES), UNSEALED
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The complete requirements for acquiring the switch described herein shall consist of this specification and
the latest issue of MIL- PRF-8805.
MS27217-2
MS27217-1
MS25476-1
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.088
2.24
.250
6.35
.002
0.05
.093
2.36
.406
10.31
.005
0.13
.100
2.54
.437
11.10
.010
0.25
.125
3.18
.446
11.33
.080
2.03
.187
4.75
.500
12.70
.781
19.84
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general
information only.
3. Unless otherwise stated, tolerance is ±.015 (0.38 mm).
4. Exact shape of switch optional provided dimensions specified are not exceeded.
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5930
