MIL-PRF-8805/46E
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Enclosure design:
5 (Hermetic).
Temperature characteristic:
(- 65°C to + 125°C).
M8805/46-001:
(- 65°C to + 260°C).
M8805/46-002:
(- 125°F to + 350°F).
M8805/46-003:
Shock type: M (100 g, test condition I, method 213 of MIL-STD-202).
Vibration grade: 2 (10 Hz to 2,000 Hz ), except that the acceleration level shall be 30 G (M8805/46-001
and 002) or 40 G (M8805/46-003).
Weight: See table I.
Operating characteristics:
See table I.
Contact resistance:
M8805/46-001 and 002:
125 milliohms maximum.
M8805/46-003:
125 milliohms maximum initial, 1.0 ohm maximum during and after life
test.
Dielectric withstanding voltage:
Sea level: 1,250 V rms for one second.
Low level circuit (M8805/46-003 only): 15,000 cycles.
Electrical and mechanical endurance: 15,000 cycles at 10 to 12 cycles per minute.
Short circuit: 90 amperes maximum.
Electrical ratings: See table II.
Part or Identifying Number (PIN): See table I.
TABLE I. PIN's and operating characteristics.
Actuating
Differential
Maximum
PIN
Release force
Over travel
Termination
force
travel
weight
Solder
.020 pound
.006 inch min.
.020 inch max
6 oz min.
26 oz max.
M8805/46-001
Solder
.020 pound
.006 inch min.
.020 inch max.
6 oz min.
26 oz max.
M8805/46-002
Solder
.020 pound
.006 inch min.
.020 inch max.
6 oz min.
32 oz max.
M8805/46-003
3
