MIL-PRF-8805/25F
TABLE III. Qualification inspection (group submission).
Examination or test
Basic switch
Additional sample units
Extent of
assembly
for combined submission
Approval
Group I
Visual and mechanical examination
M8805/25-004 (2 sample units each):
Operating characteristics
(12 sample units) M8805/25-001
M8805/25-002
M8805/25-003
(tested to group I only)
Group II
Strength of actuating means 1/
(4 sample units
---
from group I)
Strength of mounting bushing 1/
Thermal shock
Vibration
Shock
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
All
Group III
Salt spray (corrosion)
(2 sample units
---
from group I)
Visual and mechanical examination
Group IV
Low temperature operation (2 sample
---
(4 sample units
units only)
from group I)
Mechanical endurance at low
temperature (2 units) 2/
Mechanical endurance at high
temperature (2 sample units only)
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
Group V
Electrical endurance
(2 sample units
---
Inductive load, dc
from group I)
1/ Two sample units only.
2/ Same sample units as for low temperature operation.
3
