MIL-PRF-8805/23J
TABLE II. Qualification inspection (group submission).
Additional sample units for
Extent of
Examination or test
Basic switch assembly
combined submission
Approval
Group I
Visual and mechanical examination
M8805/23-004 or -104
(2 sample units each):
M8805/23-001 or -101
M8805/23-002 or -102
M8805/23-003 or -103
Operating characteristics
(12 sample units)
M8805/23-004 or -104
M8805/23-005 or -105
(tested to group I only)
Group II
Strength of actuating means 1/
Strength of mounting bushing 1/
Thermal shock
Vibration
(4 sample units from
---
group I)
Shock
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
All
Group III
Salt spray (corrosion)
(2 sample units from
---
group I)
Visual and mechanical examination
Group IV
Low temperature operation
(2 sample units only)
Mechanical endurance at low
temperature (2 units) 2/
(4 sample units from
Mechanical endurance at high
---
group I)
temperature (2 sample units only)
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
Group V
Electrical endurance
(2 sample units from
---
Inductive load, dc
group I)
1/ Two sample units only.
2/ Same sample units as for low temperature operation.
4
