MIL-PRF-8805/22D
Table I. Electrical ratings.
Sea level
50,000 feet
Load
28 V dc
115 V ac 60 Hz
28 V dc
Amperes
Amperes
Amperes
5.0
5.0
Resistive
5.0
Inductive
3.0
5.0
2.5
2.4
1.5
2.4
Lamp
TABLE II. Qualification inspection.
Examination or
Basic
Other switch
Extent of
test
switch
samples
approval
M8805/22-002
(2 sample units)
All
1. Terminal strength.
M8805/22-001
Qualification
2. Dielectric withstanding voltage.
(all sample units)
inspection
3. Visual and mechanical examination.
table of MIL-
PRF-8805
Table III. Part or Identifying Number (PIN) and terminal style.
PIN
Terminal style
Single turret
M8805/22-001
Double turret
M8805/22-002
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5930-1126-07)
DLA - CC
Review activities:
Army AV, MI
Navy - AS, MC, OS, SH
Air Force - 19
4
