MIL-PRF-8805/19F
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Enclosure design: 1 (unsealed).
Temperature characteristic: 1 (-55°C to +85°C).
Shock type: Method 213, test condition A, MIL-STD-202 (50 g).
Vibration grade: 1 (10 to 500 Hz)
Weight: .06 pound maximum.
Operating characteristics:
Actuating force ................. 3.18 pounds maximum
Movement differential ....... .065 inch maximum.
Pretravel ........................... .093 inch maximum.
Overtravel ......................... .015 inch minimum.
Strength of actuating means: 25 pounds.
Terminal strength: 5 pounds (-1); 5 pound pull and 5 pound-inch torque (-2).
Mechanical endurance: 100,000 cycles.
Electrical endurance: 50,000 cycles.
Electrical ratings: See table I.
Short circuit: 1,200 amperes.
Dielectric withstanding voltage: 1,000 Vrms; 1,000 Vrms between all terminals and mounting plate, and
200 Vrms between all terminals following electrical endurance.
Temperature rise: Using No. 8 wire, the temperature rise measured at the switch terminals shall not
exceed 50°C above the wire temperature measured a minimum of 12 inches from any connection.
Qualification:
Group submission: See table II.
Part number: See table III.
TABLE I. Electrical ratings.
Sea level
Load
28 V dc
115 V ac, 400 Hz
amperes
amperes
Resistive
40
30
Inductive
30
20
Motor
15
10
