MIL-PRF-8805/17G
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Enclosure design: 1 (unsealed).
Temperature characteristic: 1 (-55°C to +85°C).
Shock type: Method 213, test condition A, MIL-STD-202 (50 g).
Vibration grade: 1 (10 to 500 Hz)
Weight: .05 pound maximum.
Operating characteristics:
Actuating force ................. 1.75 pounds maximum
Movement differential ....... .036 inch maximum.
Pretravel ........................... .075 inch maximum.
Overtravel ......................... .015 inch minimum.
Reset button:
Pretravel
.075 inch maximum.
Overtravel
.005 inch minimum.
Strength of actuating means: 25 pounds.
Terminal strength: 5 pounds.
Mechanical endurance: 100,000 cycles. At 0.015 +.001, -.000 inch overtravel.
Electrical endurance: 50,000 cycles.
Electrical ratings: See table I.
Dielectric withstanding voltage: 1,000 V rms.
Part number: MS25353-1. (MS25353 was superseded by MIL-PRF-8805/17; the MS25353 Part
Number (PIN) was retained.)
TABLE I. Electrical ratings.
Sea level
Load
28 V dc
115 V ac, 400 Hz
amperes
amperes
Resistive
15
15
Inductive
10
15
Lamp
10
6
3
