MIL-PRF-8805/14F
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Enclosure design: 1 (unsealed).
Temperature characteristic: 1 (-55°C to +85°C).
Shock type: Method 213, test condition A, MIL-STD-202 (50 g).
Vibration grade: 1 (10 to 500 Hz)
Weight: .03 pound maximum.
Operating characteristics:
Actuating force ................. .62 pound maximum
Movement differential ....... .025 inch maximum.
Pretravel ........................... .060 inch maximum.
±20 percent variation
from specified
Overtravel ......................... .015 inch minimum.
values acceptable
Reset button:
after test.
Pretravel
.060 inch maximum.
Overtravel
.005 inch minimum.
Strength of push button and push button stop: 25 pounds.
Terminal strength: 5 pounds.
Material: Case, cover, and push button: Push button may be flame retardant glass filled with nylon
which is self extinguishing.
Dielectric withstanding voltage:
Sea level: 1,000 V rms. After electrical endurance, the dielectric withstanding voltage points of
application between all unconnected terminals of the same pole is not applicable.
Mechanical endurance: 100,000 cycles.
Electrical endurance: 50,000 cycles.
Electrical ratings: See table I.
Qualification:
Group submission: See table II.
Part Number: See table III.
TABLE I. Electrical ratings.
Sea level
Load
28 V dc
115 V ac, 400 Hz
amperes
amperes
Resistive
10
10
Inductive
10
10
Lamp
6
6
3
