MIL-PRF-8805/109C
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
.03
.020
.51
.063
1.60
.096
2.44
.188
4.78
.374
9.50
.002
.05
.030
.76
.070
1.78
.120
3.05
.255
6.48
.510
12.95
.005
.13
.040
1.02
.087
2.21
.156
3.96
.290
7.37
.010
.25
.060
1.52
.088
2.24
.180
4.57
.320
8.13
.015
.38
.062
1.57
.090
2.29
.187
4.75
.350
8.89
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specifies, tolerances are ± .010 (.25 mm).
3. Metric equivalents are given for general information only.
4. Mounting holes will accept pins or screws of .087 maximum diameter on .188 ± .002 centers.
5. Double turret terminals shall accept two AN-20 wires or equivalent.
FIGURE 1. Configuration and dimensions.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Enclosure design: 1 (unsealed)
Temperature characteristics: 1 (- 55° C to + 85° C).
Shock type: M (100 g).
Vibration grade: 1 (10 to 500 Hz).
Weight: .003 pounds maximum.
Operating characteristics:
Actuating force: 5 ounces maximum.
Release force: 1 ounce minimum.
Movement differential: .005 inch maximum.
Pretravel: .020 inch maximum.
Overtravel: .004 inch minimum.
Terminals: Terminal finish may be .000030 inch minimum to .000100 inch maximum thick gold plate
or equivalent.
Terminal strength: 5 pounds, all directions.
Mechanical endurance: 50,000 cycles at .004 + .001, -.000 inch overtravel.
Dielectric withstanding voltage:
Sea level: 1050 V rms.
Altitude (50,000 ft); 400 V rms.
Electrical endurance: 25,000 cycles.
Electrical ratings: See tables I and II.
