MIL-PRF-83504C
SUPPLEMENT 1
TABLE I. Application information for active specification sheets.
Other special
Electrical
MIL-PRF-83504/
Actuator
Stations
Enclosure
performance/
rating
design
design
at 24 V dc
requirements
1
Rocker SPST
1 to 12
Sealed base
25 mA
Standard profile
2
Rocker SPST
1 to 12
Sealed base
25 mA
Low profile
3
Slide SPST
1 to 12
Open base
25 mA
4
Slide SPST
1 to 12
Closed base
25 mA
5
Rocker SPDT
2 to 4
Sealed base
25 mA
Standard profile
6
Recessed Rocker SPDT
2 to 4
Sealed base
25 mA
Standard profile
7
Rocker DPDT
1 or 2
Sealed base
25 mA
Standard profile
8
Recessed Rocker DPDT
1 or 2
Sealed base
25 mA
Standard profile
9
Toggle SPDT
2 or 3
Sealed base
25 mA
Standard profile
10
Toggle DPDT
1 or 2
Sealed base
25 mA
Standard profile
11
Slide Toggle SPST
4 to 10
Sealed base
25 mA
Low profile
12
Recessed Slide SPST
2 to 12
Sealed base
25 mA
Machine insertable
Sealed base
15 mA
Binary coded
13
Rotary
10 or 16
positions
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5930-2005-029)
DLA - CC
Review activities:
Army - AR, AV, MI
Navy - AS
Air Force 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil/ .
2
